| Category |
Details |
| Display |
Panel Size: 75"
Panel Type: TFT LCD Module with DLED Backlight.
Display Area (mm): 1650.24mm(H) x 928.26mm(V) (74.5” diagonal)
Aspect Ratio: 16:9
Resolution: UHD 3840x2160(Pixels)
Colors: 1.07B colors
Brightness: 400 nits (typ.)
Contrast Ratio: 1200:1 (typ.)
Response Time: 6.5 ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 Hours (Min)
Surface Treatment: Hardness:9H, Anti-glare coating
Orientation: Landscape |
| Platform |
Processor: Octa-Core CPU
RAM: 16GB
Storage: 128GB |
| Touch |
Type/ Tech: Ultra Fine Touch Technology (IR Recognition)
Touch Resolution: 32767 x 32767
Touch Point: EDLA/Android/Windows: 50 points of touch
Palm Rejection: Yes |
| INPUT |
HDMI: x4 (Frontx1:HDMI2.1 with CEC, HDCP ; Rearx3:HDMI2.1 with CEC, HDCP)
RGB / VGA: x1
DisplayPort: x1
Audio: x1 (PC audio in)
RS232: x1
SD/SDHC: TF Card Slot(Micro SD)
OPS: x1 PC Slot |
| OUTPUT |
HDMI: x1 (HDMI 2.1, HDCP 1.x)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)
RS232: x1
LAN: RJ45: x2
USB: Type A: x5 [Front x2 with USB3.2 Gen 1 (all support Smart ; Rear x 2 with USB 3.2 Gen 1 (all support Smart) ; Rear x 1 with USB2.0 (for system update)]
Type B: x2 (Front x 1: USB3.2, Gen 1 ; Rear x 1:USB 2.0)
Type C: x3 (Frontx1 with USB3.2 Gen 1, DP1.2, Ethernet 100M, PD 65W; Rearx1 with USB3.2 Gen 1, DP1.2, Ethernet 100M, PD 15W; Topx1 with USB3.2 Gen 1, PD 15W for camera mounting) |
| SPEAKERS |
25W x 2 front soundbar + 25W x 1 subwoofer |
| MICROPHONE |
Built-in 8-array microphone |
| Top Camera Plate |
Yes |
| COMPATIBILITY |
RGB PC/HDMI PC: 1920x1080 @ 60Hz
HDMI: 3840x2160
DisplayPort: 3840x2160 |
| Embedded OS |
Android 14 EDLA |
| Bundle Software |
Basic Annotation Software: myViewBoard for Android
Pro Annotation Software: myViewBoard for Windows (embedded in VPC)
Wireless Presentation: AirSync
Device Management: Manager
ViewSonic Launcher: Yes
Zoom: Yes |
| Special Features |
All-in-one USB port: USB 3.0 “SmartPort USB” to all channels
Simple LAN sharing between IFP and slot-in device: 10/100/1000M (USB Type-C 10/100, Android & PC 10/100/1000)
Light Sensor: Yes
NFC Reader: Yes
Pen Sensor: Yes |
| Power |
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: TBD (Typ.) ;
< 0.5 W ("Off") |
| ERGONOMICS |
Wall Mount (VESA® ): 800 x 400 |
| OPERATING CONDITIONS |
Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80% RH non-condensing |
| DIMENSIONS (W x H x D) |
Physical (inch / mm): 67.29 x 40.85 x 3.36 in / 1709.1 x 1037.5 x 85.5 mm
Packaging (inch / mm): 73.35 x 45.79 x 8.86 in / 1863 x 1163 x 225 mm |
| WEIGHT |
Net (lb / kg): 101.54 lb / 46.06 kg
Gross (lb / kg): 126.88 lb / 57.55 kg |
| REGULATIONS |
cTUVus, FCC ID/IC ID, FCC SDoC, Energy Star 8.0, EMC/CE, CB/LVD, GOST-R/EAC, UkrSEPRO, EPEAT Silver, UK-EEL, BSMI, BIS, LBL( Low Blue Light Certification), Flicker Free, RoHS, ErP-Eco, REACH, SCIP, WEEE, TPCH , Packing waste, CA65, PAIA |
| PACKAGE CONTENTS |
1. Power Cord x1 3 meters, by ship area (VSA: US / VSE: UK, EU / VSI: UK, AU / VSCN: CN)
2. USB Type-C cable x1 1.8 meters, USB-IF certified
3. USB Touch cable x1 3 meters
4. Touch pen (Passive pen) x 2 (VB-PEN-002)
5. Quick Start Guide
6. RS232 adapter x1
7. Clamp x 5
8. Camera Plate x1
9. Screw x 8 (camera 2+2, wall mount 4)
10. HDMI cable x1 3meters, (HDMI LA certified)
11. Remote controller x1
12 AAA battery x2
13. Compliance statement |
| Compatible Slot-in PC |
VPCF5-W33-G1
VPC37-W53-G1
VPC35-W53-G1
VPC-A31-O1 |
