| Display |
- Panel Size: 86"
- Panel Type: TFT LCD Module with DLED Backlight
- Display Area: 1895.04mm (H) x 1065.96mm (V)
- Aspect Ratio: 16:9
- Resolution: UHD 3840x2160 (Pixels)
- Colors: 1.07 billion colors
- Brightness: 400 nits (typ.)
- Contrast Ratio: 1200:1 (typ.)
- Response Time: 8 ms
- Viewing Angles: H=178, V=178 (typ.)
- Backlight Life: 50,000 hours (min)
- Surface Treatment: Hardness 9H, Anti-glare coating
- Orientation: Landscape
|
| Platform |
- Processor: Octa-Core CPU
- RAM: 16GB
- Storage: 128GB
|
| Touch |
- Type/Tech: Ultra Fine Touch Technology (IR Recognition)
- Touch Resolution: 32767 x 32767
- Touch Points: 50 points for Android/Windows
- Palm Rejection: Yes
|
| Inputs |
- HDMI: x4 (1 Front, 3 Rear; HDMI 2.1 with CEC, HDCP)
- RGB/VGA: x1
- DisplayPort: x1
- Audio: x1 (PC audio in)
- RS232: x1
- SD/SDHC: TF Card Slot (Micro SD)
- OPS: x1 (PC Slot)
|
| Outputs |
- HDMI: x1 (HDMI 2.1, HDCP 1.x)
- Audio: x1 (Earphone out)
- SPDIF: x1 (Optical)
- RS232: x1
- LAN (RJ45): x2
- USB:
- Type A: x5 (2 Front USB 3.2 Gen 1, 2 Rear USB 3.2 Gen 1, 1 Rear USB 2.0)
- Type B: x2 (1 Front USB 3.2 Gen 1, 1 Rear USB 2.0)
- Type C: x3 (1 Front USB 3.2 Gen 1, DP1.2, Ethernet 100M, PD 65W; 1 Rear USB 3.2 Gen 1, DP1.2, Ethernet 100M, PD 15W; 1 Top USB 3.2 Gen 1, PD 15W for camera mounting)
|
| Speakers |
25W x 2 Front Soundbar + 25W x 1 Subwoofer |
| Microphone |
Built-in 8-Array Microphone |
| Compatibility |
- RGB PC/HDMI PC: 1920x1080 @ 60Hz
- HDMI: 3840x2160
- DisplayPort: 3840x2160
- Embedded OS: Android 14 EDLA
- Software:
- Basic Annotation Software: myViewBoard for Android
- Pro Annotation Software: myViewBoard for Windows (embedded in VPC)
- Wireless Presentation: AirSync
- Device Management: Manager
- ViewSonic Launcher: Yes
|
| Special Features |
- All-in-one USB Port: USB 3.0 “SmartPort USB” to all channels
- Simple LAN Sharing: 10/100/1000M (USB Type-C, Android & PC)
- Light Sensor: Yes
- NFC Reader: Yes
- Pen Sensor: Yes
|
| Power |
- Voltage: 100-240VAC +/- 10% (Wide Range)
- Power Consumption: 104W ("On"), < 0.5W ("Off")
|
| Ergonomics |
Wall Mount (VESA®): 800 x 600 |
| Operating Conditions |
- Temperature: 0°C to 40°C
- Humidity: 20% ~ 80% RH (non-condensing)
|
| Dimensions |
- Physical: 77.05 x 46.36 x 3.36 in (1957 x 1177.6 x 85.5 mm)
- Packaging: 83.07 x 51.34 x 8.86 in (2110 x 1304 x 225 mm)
|
| Weight |
- Net: 128.88 lb (58.46 kg)
- Gross: 156.59 lb (71.03 kg)
|
| Regulations |
cTUVus, FCC ID/IC ID, FCC SDoC, Energy Star 8.0, EMC/CE, CB/LVD, GOST-R/EAC, UkrSEPRO, EPEAT Silver, UK-EEL, BSMI, BIS, LBL (Low Blue Light Certification), Flicker Free, RoHS, ErP-Eco, REACH, SCIP, WEEE, TPCH, Packing Waste, CA65, PAIA |
| Package Contents |
- Power Cord x1 (3 meters)
- USB Type-C Cable x1 (1.8 meters, USB-IF certified)
- USB Touch Cable x1 (3 meters)
- Touch Pen (Passive) x2 (VB-PEN-002)
- Quick Start Guide
- RS232 Adapter x1
- Clamp x5
- Camera Plate x1
- Screws x8 (2 for camera, 4 for wall mount)
- HDMI Cable x1 (3 meters)
- Remote Controller x1
- AAA Batteries x2
- Compliance Statement
|
