Viewsonic ViewBoard IFP7553 75" 4K Interactive Display
Viewsonic ViewBoard IFP7553 75" 4K Interactive Display
Viewsonic ViewBoard IFP7553 75" 4K Interactive Display
Viewsonic ViewBoard IFP7553 75" 4K Interactive Display
Viewsonic ViewBoard IFP7553 75" 4K Interactive Display
Viewsonic ViewBoard IFP7553 75" 4K Interactive Display

Viewsonic ViewBoard IFP7553 75" 4K Interactive Display

Brand: Viewsonic

Status: Up Comming

  • NFC and SSO sign-in for swift access to the intuitive launcher and personal settings
  • Quick-start annotation, sketching, and four-color switching with the stylus
  • Octa-core CPU with 8GB RAM and 8GB virtual memory for smooth multitasking
  • Four USB-C ports ensure seamless connectivity, supporting up to 100W charging
  • Android 14 with integrated ViewSonic Education Software
1

Model: No Model

Display Specifications

Category Specification
Panel Size 75"
Panel Type TFT LCD Module with DLED Backlight
Display Area (mm) 1650.24 (H) x 928.26 (V) (74.5" diagonal)
Aspect Ratio 16:9
Resolution UHD 3840x2160(Pixels)
Colors 1.07B colors
Brightness 450 nits
Contrast Ratio 5500:1 (Typ.) / 5000:1 (Min. with DCR enabled)
Response Time 6.5 ms
Viewing Angles H = 178, V = 178 typ.
Backlight Life 50,000 hrs
Surface Treatment Hardness: 7H. Anti-glare coating
Orientation Landscape

Platform Specifications

Category Specification
Processor Octa-Core CPU (A73*4 + A53*4)
RAM 8GB (Physical RAM) + 8GB (Virtual RAM)
Storage 128GB

Touch Specifications

Category Specification
Type/Tech UFT (Ultra Fine Touch) Technology
Touch Resolution 32767 x 32767
Touch Points Windows: 40 points touch, Android: 20 points touch

Input/Output Specifications

Category Specification
HDMI x4 (Frontx1: HDMI2.1 with CEC; Rearx3: (HDMI2.1 with CEC)x2 & (HDMI2.1 with CEC, ARC)x1)
RGB / VGA x1
DisplayPort x1
Audio x1 (PC audio in)
RS232 x1
OPS module slot x 1
USB Type A USB3.0x4 (Frontx2; Rearx2), USB2.0x1 (Rear)
USB Type B USB3.0x3 (Frontx1; Rearx2)
USB Type C Input: x3 (Frontx1 with USB3.0, DP1.2, Ethernet 100M, PD 100W; Rearx1 with USB3.0, DP1.2, Ethernet 100M, PD 65W; Rearx1 with USB3.0, PD 15W); Output: x1, DP

Special Features

Category Specification
All-in-one USB port USB 3.0 “SmartPort USB” to all channels.
Simple LAN sharing 10/100/1000M (USB Type-C 10/100, Android & PC 10/100/1000)
Light Sensor Yes
NFC Reader Yes
Pen Sensor Yes

Power Specifications

Category Specification
Voltage 100-240VAC +/- 10% Wide Range
Consumption On: 101.77W / Off: <0.5W

Ergonomics & Dimensions

Category Specification
Wall Mount (VESA®) 800 x 400
Physical Dimensions 67.21 x 41.7 x 4.66 in / 1707 x 1059.2 x 118.4 mm
Packaging Dimensions 74.8 x 45.67 x 8.46 in / 1900 x 1160 x 225 mm

Weight

Category Specification
Net Weight 113.98 lb / 51.7 kg
Gross Weight 140.87 lb / 63.9 kg

Description

Viewsonic ViewBoard IFP7553 75" 4K Interactive Display

Elevate your interactive learning experience with the Viewsonic ViewBoard IFP7553, a cutting-edge 75-inch 4K interactive display designed to foster collaboration, creativity, and productivity. This dynamic display is part of the ViewBoard IFP53 Series, bringing powerful technology to classrooms, meeting rooms, and collaborative spaces.

Key Features:

  • Ultra-Clear 4K Resolution: The 75-inch 4K display ensures crystal-clear visuals, bringing content to life with vibrant colors and detailed images for an immersive interactive experience.

  • Android 14 & Powerful Performance: The ViewBoard is powered by Android 14, featuring a high-performance octa-core processor, 8GB of RAM, and 8GB of virtual memory, providing smooth and efficient operation, even during intensive multitasking.

  • Quick Start & Easy Annotation: With the quick-start annotation feature, you can begin writing and sharing ideas the moment inspiration strikes. The board allows you to instantly switch between four colors, perfect for brainstorming and highlighting key concepts in real time.

  • Enhanced Connectivity & Personalization: The SSO (Single Sign-On) and NFC card sign-in functions provide fast access to personalized launchers and cloud storage, ensuring a streamlined user experience and quick access to files, notes, and content.

  • ViewSonic Education Software: Designed with education in mind, the integrated ViewSonic Education Software equips teachers with interactive digital tools that enhance collaboration, engagement, and learning outcomes.

  • Interactive and Collaborative Tools: Perfect for modern classrooms or meetings, the ViewBoard enables real-time annotation, content sharing, and interactive lessons, promoting active participation and creativity among students or colleagues.

  • Seamless Integration: With its intuitive user interface and compatibility with a variety of devices and platforms, the ViewBoard makes it easy to integrate into your existing classroom or conference room setup.

The Viewsonic ViewBoard IFP7553 75" 4K Interactive Display is a game-changing solution that transforms how you engage with content, making it an ideal choice for classrooms, conference rooms, or any space that requires high-level interactivity. It’s designed to provide not just a display, but an interactive hub for creativity, collaboration, and learning.
