Output |
- Max Configurable Power (Watts): 6.0kWatts / 6.0kVA
- Output Voltage Note:Configurable for 220 : 230 or 240 nominal output voltage
- Efficiency at Full Load: 94.0 %
- Output Voltage Distortion: 1 %
- Output Frequency (sync to mains): 50/60 Hz +/- 3 Hz Sync to mains
- Other Output Voltages: 220 V, 240 V
- Load Crest Factor: 3 : 1
- Topology: Double conversion online
- Waveform type: Sine wave
- Bypass: Internal bypass (automatic and manual)
|
Input |
- Input frequency: 40 - 70 Hz Auto sensing
- Input voltage range for main operations: 110 - 300 Half load, 176 - 300 Full loadV
- Efficiency at Full Load: 94.0 %
- Other Input Voltages: 220 V, 240 V
|
Batteries & Runtime |
- Battery type: Lead-acid battery
- Typical recharge time: 7hour(s)
- Nominal Battery Voltage: 192 V
- Expected Battery Life (years): 3 - 5
- Battery Charge Power (Watts): 235 Watts
|
Communications & Management |
- Interface Port(s): DB-9 RS-232, Intelligent Smart Slot, USB
- Control panel: Multifunction LCD status and control console
- Audible Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- Emergency Power Off (EPO): Yes
- Available SmartSlot™ Interface Quantity: 1
|
Surge Protection and Filtering |
- Surge energy rating: 600Joules
|
Physical |
- Maximum Height: 685MM, 68.5CM
- Maximum Width: 190MM, 19.0CM
- Maximum Depth: 374MM, 37.4CM
- Net Weight: 54.0KG
- Shipping weight: 66.0KG
- Shipping Height: 910MM, 91.0CM
- Shipping Width: 290MM, 29.0CM
- Shipping Depth: 495MM, 49.5CM
- Color: Black
|
Environmental |
- Operating Temperature: 0 - 40 °C
- Operating Relative Humidity: 0 - 95 (Non-condensing) %
- Operating Elevation: 0 - 3000meters
- Storage Temperature: -15 - 60 °C
- Storage Relative Humidity: 0 - 95 (Non-condensing) %
- Storage Elevation: 0 - 15000meters
- Audible noise at 1 meter from surface of unit: 55.0dBA
- Online thermal dissipation: 1172.0BTU/hr
- Protection Class: IP20
|
Conformance |
- Approvals: CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, TISI
|
Sustainable Status |
|
Warranty |
|
