| Model |
10KS |
| Capacity |
10kVA / 10kW |
| Input Voltage |
208/220/230/240VAC, L+N+PE |
| Input Voltage Range |
110–300VAC |
| Input Frequency |
40–70Hz |
| Input Power Factor |
>0.99 |
| Input THDi |
<3% (Linear Load), <5% (Non-linear Load) |
| Output Voltage |
208/220/230/240VAC, L+N+PE |
| Voltage Regulation |
±1% |
| Output Frequency |
50/60Hz ±0.1% |
| Crest Ratio |
3:1 |
| Output THDu |
≤2% (Linear Load), ≤5% (Non-linear Load) |
| Transfer Time |
Line to Battery: 0ms; Inverter to Bypass: 4ms (Typical) |
| Output Power Factor |
1.0 |
| Waveform |
Pure Sine Wave |
| Overload Capacity (Line Mode) |
30min @102–110% Load; 30min @110–130% Load; 30s @130–150% Load; <200ms @>150% Load |
| Overload Capacity (Battery Mode) |
10min @102–110% Load; 1min @110–130% Load; 10s @130–150% Load; <200ms @>150% Load |
| Line Mode Efficiency |
≥96% |
| ECO Mode Efficiency |
≥98.5% |
| Battery Energy |
1536.0Wh |
| Backup Time (100% Load) |
2.5 Minutes |
| Backup Time (50% Load) |
9.5 Minutes |
| Charging Time |
<1 Hour (25°C) |
| Communication |
RS232 / USB Port / SNMP Card (Optional) / Dry Contact Kit (Optional) |
| Operating Temperature |
-20°C to 40°C |
| Storage Temperature |
-20°C to 50°C |
| Relative Humidity |
0–95% (Non-condensing) |
| Noise Level |
<58dB @1 Meter |
| Operating Altitude |
Up to 1000m (Without Derating) |
| Standards |
EN/IEC 61000, EN/IEC 62040 |
| Product Dimensions (W×D×H) |
390 × 190 × 320 mm |
| Packing Dimensions (W×D×H) |
500 × 285 × 430 mm |
| Net Weight |
11.2 kg |
