| OC |
BOE MV270FHB-NF6 |
| Panel Type |
IPS |
| Curvature |
Flat |
| Size |
27” |
| Panel area |
606.888×347.312 mm (H×V)mm |
| Active area |
597.888×336.312 mm (H×V)mm |
| Aspect Ratio |
16:9 |
| Resolution (HxV) |
1920*1080/FHD |
| Refresh rate（Max） |
240HZ |
| Response Time（GTG） |
MPRT 1MS |
| Viewing Angle |
178°/178° |
| Color Support |
16.7M |
| Contrast Ratio)(Typ.) |
1000:1 |
| Backlight Technology |
WLED |
| Brightness(Max.) |
300nit |
| Brightness Uniformity |
≥75% |
| Surface Treatment |
(Haze 25%)，Hard coating (3H) |
| Color Gamut |
SRGB |
120.00% |
| NTSC |
85.00% |
| Bezel |
3-sided Bezeless |
| Rear Cover |
Plastic Rear cover |
| Base |
Fixed Metal Stand |
| （Base） |
Tilt |
（+5°,- 15°）±2° |
| Height |
/ |
| Swivel |
/ |
| Pivot Rotation |
/ |
| Disassembly |
/ |
| Vesa function |
Vesa size |
75*75mm |
| Screws |
M4 |
| Dimensions |
(L*W*H）(With stand) |
614*166*470mm |
| （L*W*H）(Without stand) |
614*55*364mm |
| Package |
(L*W*H) (Dimensions) |
675*102*431mm |
| Net weight (including base) |
4.0KG |
| Gross weight |
5.0KG |
| IC |
MTK9701/HDMI+DP+AUDIO OUT |
| Port Location |
Bottom of the shell |
| (Interface) |
VGA |
/ |
| DVI |
/ |
| HDMI |
1*HDMI 2.0 (1920*1080@240HZ) |
| DP |
1*DP 1.4 (1920*1080@240HZ) |
| Type-C |
/ |
| USB |
/ |
| Audio in |
/ |
| USBHUB |
USB-A |
/ |
| USB-B |
/ |
| (Audio) |
Audio out |
1 |
| Speaker |
YES (4Ω，3W) |
| HDCP |
/ |
| Indicator light |
Power on : Blue(LED)
Power saving : Flashing Blue (LED) |
| Atmosphere Light |
/ |
| Key board |
Location |
Bottom of the fuselage |
| Function |
Five-way remote sensing button |
| Color temperature |
Warm （6500K)/Cool(9300K)/standard(7500K)//User |
| Preset Mode |
6500K |
| Language |
English |
| Low Blue Light |
Yes |
| Flicker-free |
Yes |
| HDR |
Yes |
| AMD-Freesync |
Yes |
| ECO |
Yes |
| E-Book |
Yes |
| MPRT |
Yes |
| OverDriver |
Yes |
| PBP/PIP |
/ |
| Ai Vision |
Yes |
| Shadow Boost |
Yes |
| Color Gamut Reduction |
/ |
| Six-axis color grading |
/ |
| Refresh rate display |
Yes |
| Timer |
Yes |
| Type |
Adapter UK (Wall Plug) |
| Input Voltage |
12V |
| Input Electric Current |
3A |
| Power Consumption |
On |
≥36W |
| Stand by(max)） |
0.5W |
| USBC/Thunder bolt3) |
/ |
| Cantron |
Material |
Color box |
| Carry |
Handle |
| Cable Manager |
1 |
| Stand |
1 |
| User Manual |
1 |
| Screws |
4 |
| Cables |
Adapter |
YES DC 12V-3A |
| Power Cable |
No |
| HDMI Cable |
/ |
| DP Cable |
1*1.5M |
| Type-C Cable |
No |
| USB Cable |
No |
| Storage Temperature |
-20°C~60°C |
| OperatingTemperature |
0°C ~ +40°C |
| Humidity Range Operating |
20% ~ 90% RH |
| Altitude |
≤2000m |
