Processors Support Type |
Intel 6th/7th/8th/9th Gen, Intel Dual Core/ Core i3/ Core i5/ Core i7/ |
Chipset |
Intel 100 Series Chipset |
CPU Socket |
Support Intel LGA1151 Platform Processors |
Memory Slot |
2 x DDR4 Memory Slot |
Memory Standard |
Support Dual Channels DDR4 2666/2400/2133/ 1866MHz(Decided By CPU),Max Support32GB |
Storage Interface |
4xSATA 3.0 6Gbps |
Expansion Slots |
1xPCI Express3.0 x16,1xPCI Express 2.0 x1,2xPCI |
Expansion Interface |
1xM.2 2280 NVME PCIE X4 2.0 |
Sound Track |
Realtek High Fidelity Audio |
Network Card |
Gigabit Network Card |
Power Interface |
24PIN+8PIN |
FAN PIN |
1xCPU_FAN PIN,2xSYS_FAN PIN |
Power Supply |
6-Phase Power Supply |
PCB Layers |
4-Layer PCB |
Dimension |
240*180MM M-ATX |
Rear Panel Interface |
2xUSB3.0, 2xUSB2.0, 1xVGA Interface,1xHDMI2.0 Interface,1xCOM Interface,1x Network Card Interface,
1×3-Hole Audio Interface,1xPS/2 Interface,1xJVGA PIN
|
Front Panel Interface |
2 xUSB2.0 PIN,1 xUSB3.0 PIN,1 x Front Audio PIN,,1 x Debug PIN,1 x JBAT BIOS PIN,1 x TPM PIN,
1 x SPEAK PIN,1 x Power On/Restart PIN
|
Support System |
Windows7 Windows10 Windows11(Restore AC Power Loss/Scheduled Power On/Wake-on-LAN/IPV4/IPV6 PXE Boot) |
BIOS |
AMI UEFI BIOS |
Packing List |
1 x Motherboard,1x SATA Cable,1xWarranty Card,1xIO PANEL |
